DOREX F425T: The Ultimate in Access Flexibility
Introducing the DOREX F425T electronic lever locksets, the 3-in-1 solution for secure and flexible access. Whether you prefer a physical key, access code, or RFID token, the F425T meets your needs.
Ideal for Offices, Conference Rooms, Maintenance Areas, Laundry Rooms, and More.
Key Features
- Versatile Access Options: Use a physical key, access code, or RFID token.
- Standards Compliance: Conforms to ANSI/BHMA A156.5, Grade 2.
- Suitable for doors 1⅜ to 2″ (35 to 51 mm) thick.
- Non-handed Design: Fits both left and right-handed doors.
- Adjustable Backset: Compatible with 2⅜″ or 2¾″ (60 mm or 70 mm) backset.
- Robust Construction: Zinc alloy deadlatch with a ½″ (12.7 mm) throw.
- Easy Installation: Fits standard door preparations without additional holes or wiring.
- Secure Keying: Equipped with a 5-pin Schlage “C” brass cylinder and includes 2 keys.
- Customizable Keying: Other keying options are available upon request
Digital and RFID Features
- Touch Keypad: Digital touch keypad with a blue LED backlight for ease of use.
- RFID Compatibility: Utilizes MIFARETM 13.56 MHz (Classic 1K) protocol and includes 2 RFID cards.
- User Code Capacity: Supports 50 individual user codes.
o Programmable Codes: 25 codes (4-8 digits).
o RFID Tokens: 25 programmable RFID tokens.
o Single Use Codes: 4 renewable single-use codes. - Auto Lock with Delay: Enhances security by automatically locking after a set delay.
- Vacation Mode: Disables the keypad when not in use.
- Random Screen Keypad Activation: Optional feature to prevent number probing.
- Double Authorization Mode: Requires both user code and RFID token for extra security.
- Simple Programming: Easy to program and pair RFID keys for user convenience.
Durable Warranties for Lasting Peace of Mind
For complete details, please refer to the Schlage warranty.
The DOREX F425T series offers unparalleled flexibility and security, making it the perfect choice for a wide range of applications. Upgrade your access control with the F425T and experience the ultimate in convenience and peace of mind.
Contact us today for more information.
(Plymouth TRIM | FE575 PLY 626 ELA)
Experience the ultimate in keyless convenience and security with the Schlage Keypad Lever or Knob with Auto-Lock. Perfect for front and back doors, garage entry doors, and home offices, this electronic lock provides robust protection and ease of use. With a heritage of excellence, Schlage ensures your home’s security with style and reliability.
Over 100 Years in Innovative Door Hardware
Key Features
Premium Security and Durability
- High-Quality Construction: Built with strong, durable metal for enhanced security.
- Grade 2/AAA Rating: Certified for top-notch security and durability in both residential and light commercial applications.
- Certified Commercial Grade 2: Ensures reliability and high performance.
Innovative Auto-Lock Design
- Auto-Lock Feature: Automatically re-locks your door 5 seconds after a code is entered, providing peace of mind even if you forget to lock it manually.
- Easy Exit: Unlocks by simply turning the door handle from the inside.
Keyless Convenience
- Pre-Programmed Codes: Comes with 2 pre-programmed codes for immediate use.
- Customizable Access: Store and manage up to 19 unique access codes for family and friends.
- Secure Keypad: Silicone-coated buttons with LED backlight for easy access in the dark.
Battery-Powered Reliability
- Long Battery Life: Operates with an included 9V battery, lasting up to 2 years with typical use.
- Low-Battery Indicator: Prevents lockouts by alerting you when the battery is low.
Easy Installation and Operation
- Simple Installation: Installs in minutes with just a screwdriver, with no hardwiring required. Fits standard doors with 1-3/8” to 1-3/4” thickness and 2-3/8” or 2-3/4” backset.
Weather-Resistant Design
- Operating Temperatures: -35°C to 66°C for the exterior escutcheon and -10°C to 50°C for the interior escutcheon, ensuring reliable performance in various weather conditions.
Specifications
- Keying: 5-pin tumbler C keyway with one nickel silver key.
- Codes: 2 pre-set unique 4-digit access codes, with storage for up to 19 access codes.
- Battery: Uses 1 9V battery.
- Operating Temperatures: Outside escutcheon: -35°C to 66°C; Inside escutcheon: -10°C to 50°C.
- Exterior Dimensions: 3.01” x 6.84” x 6.85”.
- Backset: Universal latches and deadbolts fit 2-3/8” (60mm) or 2-3/4” (70mm) backset.
- Door Thickness: Fits doors 1-3/8” to 1-3/4” thick.
- Certifications: ANSI/BHMA A156.2-2011 Grade 2.
Enjoy peace of mind with our 3-year electronics warranty and limited lifetime mechanical and finish warranty.
Trust Schlage to secure your home with the FE575 PLY 626 ELA Keypad Lever or Knob with Auto-Lock. Enjoy the perfect blend of keyless convenience, premium security, and stylish design.
Contact us today for more information.
